FINGERPRINT TIME ATTENDANCE

All models brochure
MODEL TA100C & TA100C-R TA200 Plus AC100C TA500
Click to view
SURFACE FINISHING Acrylonitrile Butadiene Styrene (ABS) Acrylonitrile Butadiene Styrene (ABS) Acrylonitrile Butadiene Styrene (ABS) Acrylonitrile butadiene styrene (ABS) & PC
TYPE OF SCANNER Non coated optical scanner Non coated optical scanner Non coated optical scanner Non coated optical scanner
MICROPROCESSOR 800 MHz 800 MHz 400 MHz 360 MHz
MEMORY 256MB flash memory and 128MB SDRAM 256MB flash memory and 64MB SDRAM 256MB flash memory and 128MB SDRAM 128MB flash memory and 16MB SDRAM
ALGORITHM BioBridge VX 9.0 / VX 10.0 BioBridge VX 9.0 / VX 10.0 BioBridge VX 9.0 / VX 10.0 BioBridge VX 10.0
DIMENSION (L X W X H), MM 190 x 52 x 140 200 x 56 x 160 195 x 48 x 144 185 x 30 x 140
STORAGE
• Fingerprint templates 8000 10000 8000 2000
• Cards N/A / 10000 10000 N/A Made to order
• Transaction 200000 200000 200000 80000
ENROLLMENT & VERIFICATION
• Methods Fingerprint (1:1, 1:N) & Password (Optional RFID Card) Fingerprint (1:1, 1:N), Card & Password Fingerprint (1:1, 1:N) & Password Fingerprint (1:1, 1:N) & password (Optional RFID card)
• Recommended fingerprint per user ID 2 2 2 2
• Fingerprint placement Any angle Any angle Any angle Any angle
• Verification time (sec) <1 <1 <1 <1
• FAR (%) < 0.0001 < 0.0001 < 0.0001 < 0.0001
• FRR (%) < 1 < 1 < 1 < 1
CARD TECHNOLOGY
• RFID: 64-bit, 125kHz Yes (TA100C-R only) Yes N/A Made to order
• MIFARE: MFIS50/S70, 13.56MHz Made to order (TA100C-MF only) Made to order N/A Made to order
• HID: HID 1325, 26-bit, 125kHz Made to order (TA100C-HID only) Made to order N/A N/A
COMMUNICATIONS
• Method TCP/IP, USB flash disk
(Optional RS232, RS485, WiFi & GPRS)
TCP/IP, USB flash disk
(Optional: RS232, RS485, POE, WiFi & GPRS. 3G only applicable to non-POE devices)
TCP/IP, USB disk
(Optional RS232 & RS485)
TCP/IP, USB disk
• Baud rates 9600 ~ 115200 9600 ~ 115200 9600 ~ 115200 N/A
OPERATING ENVIRONMENT
• Temperature (°C) 0 ~ 45 0 ~ 45 0 ~ 45 0 ~ 45
• Humidity (%) 20 ~ 80 20 ~ 80 20 ~ 80 20 ~ 80
• Power input DC 5V 2A DC 12V 3A, DC 5V 2A (POE) DC 5V 2A DC 12V 1.5A
TIME ATTENDANCE
• Siren Built- in and External Built- in (Optional-External) N/A Yes
• Work codes Yes Yes Yes Yes
MULTIMEDIA
• Voice Yes Yes Yes Yes
• Display 3.0” 65k color TFT screen 3.5” 65k color TFT screen 3.0” 65k color TFT screen 2.8″ TFT color screen
• Short messaging Yes Yes Yes Yes
• Internal backup battery N/A N/A N/A Yes (2-hours working, 4-hours standby)
VOICE / DISPLAY LANGUAGE (TERMINAL) English (Standard), Arabic, Malay, Indonesian, Chinese (Traditional), Chinese (Simplified), Cantonese, Thai, Vietnamese, Spanish, Portuguese (Portugal), Portuguese (Brazil), French, Russian, German, Turkish, Persian. Other languages are available upon request. English (Standard), Arabic, Malay, Indonesian, Chinese (Traditional), Chinese (Simplified), Cantonese, Thai, Spanish, Portuguese (Portugal), Portuguese (Brazil), French, Russian, German, Italian, Turkish, Persian. Other languages are available upon request. English (Standard), Arabic, Malay, Indonesian, Chinese (Traditional), Chinese (Simplified), Cantonese, Thai, Spanish, Portuguese (Portugal), Portuguese (Brazil), French, Russian, German, Turkish, Persian. Other languages are available upon request English (Standard), Arabic, Indonesian, Chinese Traditional / Simplified, Vietnamese, Spanish, Portuguese (Portugal), Russion, Thai, Turkish, French, Persian. Other languages are available upon request.
SOFTWARE
SOFTWARE LANGUAGE English, Arabic, Arabic (Kuwait), Chinese (Traditional), Chinese (Simplified), Persian, French, German, Indonesian, Italian, Korean, Lithuanian, Malay, Polish, Portuguese, Portuguese (Brazil), Russian, Spanish,
